PhotonicsSpectra article on quantum dots-based SWIR Imagers

Full article available here link:
https://www.photonics.com/Articles/New_Sensor_Materials_and_Designs_Deepen_SWIR/a68543

The price for SWIR cameras today can run in the tens of thousands of dollars, which is too expensive for many applications and has inhibited wider use of the technology.

Silicon, the dominant sensor material for visible imaging, does not absorb SWIR photons without surface modification — and even then, it performs poorly. As a result, most SWIR cameras today use sensors based on indium gallium arsenide (InGaAs), …

… sensors based on colloidal quantum dots (QDs) are gaining interest. The technology uses nanocrystals made of semiconductor materials, such as lead sulfide (PbS), that absorb in the SWIR. By adjusting the size of the nanocrystals used, sensor fabricators can create photodetectors that are sensitive from the visible to 2000 nm or even longer wavelengths.

… performance has steadily improved with the underlying materials and processing science, according to Pawel Malinowski, program manager of pixel innovations at imec. The organization’s third-generation QD-based image sensor debuted a couple of years ago with an efficiency of 45%. Newer sensors have delivered above 60% efficiency.

Fabricating QD photodiodes and sensors is also inexpensive because the sensor stack consists of a QD layer a few hundred nanometers thick, along with conducting, structural, and protective layers, Klem said. The stack goes atop a CMOS readout circuit in a pixel array. The technique can accommodate high-volume manufacturing processes and produce either large or small pixel arrays. Compared to InGaAs technology, QD sensors offer higher resolution and lower noise levels, along with fast response times.

Emberion, a startup spun out of Nokia, also makes QD-based SWIR cameras … The quantum efficiency of these sensors is only 20% at 1800 nm… [but] … at about half the price of InGaAs-based systems… .

[Another company TriEye is secretive about whether they use QD detectors but…] Academic papers co-authored by one of the company’s founders around the time that TriEye came into existence discuss pyramid-shaped silicon nanostructures that detect SWIR photons via plasmonic enhancement of internal photoemission.

--

--
